Terex Manlift Specifications
Terex is a Westport, Connecticut company which specializes in producing in manufacturing construction machines. Equipment like aerial lifts, manlifts and boom lifts. These machines are designed to facilitate access to difficult to reach areas, large equipment, roofs and buildings, among other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration or also called OSHA refers to a power-driven endless belt. This belt moves just in one direction and includes platforms, or steps or handholds which are attached to the unit to be able to transport personnel from each floor.
TB85
The Terex TB85 provides a maximum working height of 91 feet. Moreover, the maximum height of the platform reaches 85 feet. The maximum width of this model is 8 feet, 1 and 1/2 inches. The TB85 has dimensions that measure 9 feet, 1-inch high and 9 inches wide by 36 feet. This particular model provides a reach of seventy feet. The TB85 has a boom angle below horizontal measures at -14 degrees and above horizontal measuring 75 degrees.
Terex TB100
The maximum height of Terex's TB100 man lift is 106 feet and the maximum height of the platform is 100 feet. The TB100 when stowed away, is roughly 9 feet high by 8.5 feet wide by 8 feet. The unit's maximum width is 8 feet, 1 1/2 inches. The boom angle below horizontal is -14 degrees and above horizontal is 75 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The Terex TB110 man lift reaches a max height of 100 feet, while the max working height measures at 116 feet. The model is 9 feet, 4 inches high x 8 feet wide when stowed away. The TB110 offers a maximum width of 8 feet and a horizontal reach of 67 feet. This particular model has a boom angle of 75 degrees above horizontal plus 10 degrees articulating. It measures -105 degrees articulating and below horizontal it is -14 degrees.
